Nanovia TPE 22D : Flexible shock absorption

Starting at : 61,75 € ex. VAT/ kg

Nanovia TPE 22D is a flexible filament of a shore hardness 22D / 90A that makes it possible to 3D print shock and vibration absorbers. It has particularly strong inter lays adhesion and wear resistance.

Bulk deal
Quantity Discount Discounted price
3 - 4 2% 31,85 €
5 - 9 5% 30,88 €
10 - 14 8% 29,90 €
15 + 10% 29,25 €
SKU: N/A Categories: , , ,

Description

Properties

3D Printing

Extrusion temperature220 – 240°C
Plate temperature30 – 50°C
Enclosure temperature20°C
Nozzle (minimum)Tous
Diameter1,75 & 2,85mm+/- 50 µm
ColourTranslucid

Mechanical properties

Density1,00g/cm3ISO 1183
Traction modulus12MPaISO 527-1
Hardness22Shore D
70Shore A

Documentation

Download the technical chart Download the security chart

last updated : 08/03/2023

Nanovia TPE 22D allows for the creation of flexible parts, with excellent inter-layer adhésion. Easy to print, this material largely used for industrial shock and vibration absorption, as well as parts that need to deform dramatically.

Avantages

  • Great flexibility
  • Great inter-layer adhesion
  • Shock resistant

Application recommendations

Storage

  • Store in airtight container with desiccant, out of direct sunlight.
  • Dehydrate for 4h at 50°C prior to printing after prolonged exposure to humidity.

Printing

Due to its flexible nature, a direct drive extruder is recommended.

There should be little to no tension between the spool and the extruder to prevent the permanent stretching of the filament, which can cause under extrusion.

  • Extrusion temperature : between 220 and 240 °C
  • Heated bed temperature : between 30 and 50 °C

Post traitement

  • Due to its softness, it is not possible to sand Nanovia TPE 22D.

Health and safety

Printing

  • We recommend printing Nanovia TPE 22D in a room equipped with air extraction or by using appropriate breathing equipment. Whilst printing ABS produces a VOC derivative.

Certifications

  • Certification RoHS TPE 22D : Nanovia TPE 22D certified RoHS

Nanovia flexible filaments

comparaison des duretés Shores des différents produits Nanovia

Packaging

Vacuum packed spools, with desicant, packed in individual boxes with engraved serial number.

Other formats available on demand.

SpoolL1L2D1D2D3Weight
500g53462009052182 g
2kg928930017552668 g
www.nanovia.tech/ref/tpe-22d

Additional information

Weight N/A
Max temperature

55 °C
Diameter

1.75 mm, 2.85 mm
Weight

500 g, 2000 g, sample
